16-Bit ADC ASIC with Analog Front End

16-Bit ADC ASIC with Analog Front End

Unveil the pinnacle of precision with our advanced 16-Bit ADC ASIC featuring an Analog Frontend. This meticulously engineered solution redefines signal acquisition and processing, boasting a 16-bit ADC core for unmatched resolution. Designed with a high-performance Sample-and-Hold circuit, Programmable Gain Amplifier (PGA), and Offset Cancellation DAC, this ASIC ensures adaptability and error mitigation. With features like a 0.1 to 20 MSPS sampling rate, absence of missing codes, and low power consumption (86mW), it stands as a testament to innovation and precision in data conversion for a multitude of applications.


→  16-Bit ADC Core

→  High Performance Sample-and-Hold Circuit

→  Programmable Gain Amplifier (PGA)

→  Offset Cancellation DAC

→  Correlated Double Sampler (CDS)

→  Clamp Circuit for interfacing to CCD sensors

→  Internal Voltage Reference

→  Clock Management Unit


→  Sampling Rate: 0.1 to 20 MSPS

→  No Missing Codes

→  Monotonicity

→  INL: ±2LSB

→  Power Consumption: 86mW

→  Temperature Drift: 35 ppm/degC

→  CDS Timing: 4 to 46 ns at 20 MHz Input Clock
